CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts

    Buy cheap CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts from wholesalers

    Buy cheap CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts from wholesalers
    • Buy cheap CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts from wholesalers
    • Buy cheap CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts from wholesalers
    • Buy cheap CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts from wholesalers
    • Buy cheap CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts from wholesalers

    CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts

    Ask Lasest Price
    Brand Name : PNC
    Model Number : E323
    Payment Terms : T/T, Western Union, Paypal
    Delivery Time : 1-3 working days
    Price : USD 23-26/PC
    Supply Ability : 1000pcs/months
    • Product Details
    • Company Profile

    CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts

    CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts


    CAT Planet Carrier Parts E323 Final Drive 1st Gear Planetary 333-2991


    Description

    CAT Planet Carrier Parts, E323 Final Drive Parts, E323 1st Gear Planetary

    Application

    E323 Final Drive

    Model

    E320, E323, E325, E320D2, E323D2

    Part No.

    333-2991, 3332991, 507-6562

    Quality

    OEM quality

    Type

    Made in china, aftermarket

    Packing

    Light items pack with carton box, heavy items pack into wooden

    MOQ

    1PC

    Lead time

    About 1-3 working days

    Payment

    TT, Western union, Paypal, Paysend, RMB

    Warranty

    3 Months

    Shipping Port

    Huangpu Old Port, Shenzhen Yantian,Guangzhou


    More pictures showing:

    CAT E323 Final Drive 1st Gear Planetary 333 2991 Planet Carrier Parts


    Parts on E323 E320D2 travel gearbox 507-6562:

    Pos.

    Part No

    Qty

    Parts name

    Comments

    1.

    094-0580

    [1]

    PLATE (10-MM THK)


    2.

    094-0611

    [6]

    WASHER (47.3X76X1-MM THK)


    3.

    096-1773 B

    [1]

    SHIM (0.15-MM THK)



    096-1774 B

    [1]

    SHIM (0.3-MM THK)



    096-1775 B

    [1]

    SHIM (0.4-MM THK)



    096-1776 B

    [1]

    SHIM (0.5-MM THK)



    096-1777 B

    [1]

    SHIM (0.6-MM THK)



    096-1778 B

    [1]

    SHIM (0.7-MM THK)



    096-1779 B

    [1]

    SHIM (0.8-MM THK)



    096-1780 B

    [1]

    SHIM (1-MM THK)



    096-1781 B

    [1]

    SHIM (1.6-MM THK)


    4.

    3E-2338

    [2]

    PLUG-PIPE


    5.

    5P-8245

    [16]

    WASHER-HARD (13.5X25.5X3-MM THK)


    6.

    6D-0692

    [1]

    SEAL-O-RING


    7.

    7M-8485

    [2]

    SEAL-O-RING


    8.

    7Y-1558

    [1]

    SPACER (90X119.6X7.5-MM THK)


    9.

    8T-0348 M

    [28]

    BOLT-SOCKET HEAD (M16X2X50-MM)


    10.

    9X-8268

    [28]

    WASHER (17.5X30X3.5-MM THK)


    11.

    346-5215

    [3]

    BEARING AS


    12.

    114-1539

    [6]

    PIN-DOWEL


    13.

    148-4715

    [1]

    GEAR-COUPLING (55-TEETH)


    14.

    174-4874

    [1]

    SEAL GP-DUO-CONE


    15.

    333-2989

    [1]

    GEAR-SUN (12-TEETH)


    16.

    333-2990

    [1]

    GEAR-SUN (18-TEETH)


    17.

    333-2991

    [3]

    GEAR-PLANETARY (38-TEETH)


    18.

    333-2992

    [3]

    GEAR-PLANETARY (35-TEETH)


    19.

    333-2993

    [3]

    SHAFT


    20.

    333-2994

    [3]

    SHAFT


    21.

    333-2995

    [1]

    CARRIER-PLANETARY


    22.

    333-2996

    [1]

    CARRIER-PLANETARY


    23.

    333-2998

    [1]

    HOUSING


    24.

    455-4087

    [1]

    HOUSING-MOTOR (LH)


    25.

    457-7977

    [1]

    GEAR-RING (90-TEETH)


    26.

    480-6771

    [1]

    COVER


    27.

    498-9005

    [1]

    GASKET


    28.

    094-0584

    [6]

    WASHER (40.3X72X1-MM THK)


    29.

    095-0891

    [6]

    PIN-SPRING


    30.

    096-3216 M

    [2]

    SETSCREW-SOCKET (M12X1.75X12-MM)


    31.

    143-0811 M

    [16]

    BOLT (12X1.75X35-MM)


    32.

    165-5785

    [1]

    SPACER (40X60.9X1-MM THK)


    33.

    227-6034 M

    [14]

    BOLT-FLANGE HEAD (M16X2X60-MM)


    34.

    296-6220

    [2]

    BALL BEARING


    35.

    296-6268

    [6]

    BEARING AS-ROLLER



    B


    USE AS REQUIRED


    M


    METRIC PART



    Warranty Statement:

    1. Warranty Type: We will replace the product which have quality problem.


    2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.

    Contact with us and offer the data, photos of the problem items


    3. You need to pay for the replacement charge for following condition:

    * Wrong Order from customer.

    * Natural Disasters cause the damage.

    * Error installation, improper use.

    * The machine and reducer work over time and over load.

    * Lost by any condition.

    * Human element destroyed.

    * Corrode with rust during stock and running.

    * Warranty Expired.


    FAQ :

    Q1: How can i make payment ?

    A : Bank transfer, Western union, Paypal, Paysend, or RMB.
    bank transfer take 2-3days, while we can arrange order once received the remittance copy.


    Q2: How fast you can do shipment?

    A: Stock items take 1-2days, no stock items 5-7 working days. It depends on the items and the quantity of your order. We will try best to ship goods on time,

    won't let you and your client down.


    Q3: If we dont find what we want on your website, what should we do?

    A: talk with us directly on whatsapp, email, wechat, or phone, we will check inquirys asap. excavator parts have thousands kinds, it's not possible to post

    all production online.


    Q4. Do your product been tested before delivery?

    A: Yes, all product been tested to make sure they are qualified to sell.


    Q5: Can we buy 1 pc of each item for quality testing?
    A: Yes, we value every customer, no matter order amount small or big, with grateful for your trust.
