    SK210 6 YN15V00017S003 Hydraulic Repair Parts For KobelcoTravel Motor

    Ask Lasest Price
    Brand Name : PNC
    Model Number : Kobelco SK200-6
    Payment Terms : T/T, Western Union, Paypal
    Delivery Time : 1-3 working days
    Price : USD 650-698/SET
    Supply Ability : 1000sets/months
    • Product Details
    • Company Profile

    SK210 6 YN15V00017S003 Hydraulic Repair Parts For KobelcoTravel Motor

    SK210 6 YN15V00017S003 Hydraulic Repair Parts For KobelcoTravel Motor


    SK200-6 Travel Motor Repair Parts YN15V00017S003 Kobelco Excavator Hydraulic Parts


    Description

    SK200-6 Travel Motor Rotary Group, SK210-6 Hydraulic Repair Kit

    Application

    Kobelco Excavator

    Model

    SK210-6

    Part No.

    YN15V00017S003, YN15V00017S008,YN15V00009S005

    Quality

    OEM quality

    Weight

    10-15kgs

    Packing

    Blank box or color box

    MOQ

    1PC

    Lead time

    About 1-3 working days

    Payment

    TT, Western union, Paypal, Paysend, RMB

    Warranty

    3 Months

    Shipping Port

    Huangpu Old Port, Shenzhen Yantian,Guangzhou


    SK210 6 YN15V00017S003 Hydraulic Repair Parts For KobelcoTravel Motor


    Parts on SK200-6 SK210-6 Travel Motor Group:


    Pos.

    Part No

    Qty

    Parts name

    Comments

    . .

    YN15V00017F1

    [1]

    MOTOR

    KOB MOTOR ASSY (PROPELLING) Superseded by part number: YN15V00017F3

    1.

    YN15V00017S001

    [1]

    BODY

    KOB

    2.

    YN15V00017S002

    [1]

    COVER

    KOB

    3.

    YN15V00017S003

    [1]

    BLOCK

    KOB

    4.

    NSS

    [1]

    NOT SOLD SEPARAT

    CON RETAINER,SHOE

    5.

    YN15V00009S005

    [3]

    PLATE

    KOB

    6.

    YN15V00009S006

    [1]

    PISTON

    KOB

    7.

    YN15V00009S007

    [4]

    PLATE

    KOB

    8.

    YN15V00017S008

    [1]

    PLATE

    KOB

    9.

    YN15V00017S009

    [1]

    SHAFT

    KOB

    10.

    YN15V00017S010

    [1]

    COUPLING

    KOB

    11.

    NSS

    [1]

    NOT SOLD SEPARAT

    CON PLATE,SHOE

    12.

    NSS

    [1]

    NOT SOLD SEPARAT

    CON JOINT,BALL

    13.

    YN15V00017S013

    [1]

    SEAT

    KOB

    14.

    NSS

    [9]

    NOT SOLD SEPARAT

    CON PISTON ASSY

    15.

    YN15V00009S015

    [1]

    RING

    KOB Superseded by part number: YN15V00017S062

    16.

    YN15V00003S015

    [1]

    O-RING

    KOB Superseded by part number: YN15V00017S063

    17.

    YN15V00017S017

    [3]

    CHECK VALVE

    KOB

    18.

    ZR26X03200

    [1]

    SNAP RING

    KOB Retaining -- ID 32 x OD 34.4 x Th 1.2mm

    19.

    YN15V00009S019

    [1]

    RING

    KOB

    20.

    YN15V00017S020

    [1]

    PISTON

    KOB

    21.

    YN15V00017S021

    [1]

    BALL

    KOB

    22.

    NSS

    [2]

    NOT SOLD SEPARAT

    CON PIVOT

    23.

    YN15V00003S024

    [1]

    SEAL

    KOB

    24.

    PR30V00010S014

    [2]

    ORIFICE

    KOB

    25.

    YN15V00009S027

    [1]

    OIL SEAL

    KOB

    26.

    YN15V00017S026

    [3]

    SPRING

    KOB SPRING

    27.

    2441U820S31

    [9]

    SPRING

    KOB

    28.

    YN15V00017S028

    [12]

    SPRING

    KOB

    29.

    YN15V00017S029

    [1]

    BEARING

    KOB Superseded by part number: 86557434

    30.

    YN15V00017S030

    [1]

    BEARING

    KOB

    31.

    ZS23C16045

    [8]

    CAP,Hex Socket Head, M16 x 45mm

    KOB Screw -- M16x2.0x45mm

    32.

    YN15V00017S032

    [2]

    SHIM

    KOB

    33.

    YN15V00017S033

    [1]

    PIN

    KOB

    35.

    2436U279S3

    [1]

    PLUG

    KOB

    36.

    2436U1427S25

    [10]

    PLUG

    KOB

    37.

    2436U1749S17

    [1]

    PLUG

    KOB PLUG

    38.

    YN15V00017S038

    [3]

    PLUG

    KOB

    39.

    2436U1317S13

    [2]

    PLUG

    KOB

    40.

    ZD12P00800

    [5]

    O-RING,1.9mm Thk x 7.8mm ID, 90 Duro

    KOB ID 7.8mm x OD 9.7mm

    41.

    ZD12P01100

    [4]

    O-RING

    KOB ID 10.8mm x OD 13.2mm

    42.

    ZD12P01400

    [2]

    O-RING

    KOB ID 13.80 ± 0.19 x OD 18mm

    43.

    YN15V00009S039

    [1]

    O-RING

    KOB

    44.

    YN22V00013F1

    [2]

    VALVE

    KOB RELIEF SEE P.YN22V00013

    45.

    YN15V00017S045

    [1]

    SPOOL

    KOB

    46.

    YN15V00017S046

    [1]

    PLUG

    KOB

    47.

    2436R874S5

    [1]

    SPRING SEAT

    KOB

    48.

    2436R874S6

    [1]

    PIN

    KOB

    49.

    2436R874S7

    [1]

    SPRING

    KOB

    50.

    2436R874S3

    [1]

    FLEXIBLE JOINT

    KOB

    51.

    YN15V00017S051

    [1]

    SPOOL

    KOB

    52.

    YN15V00017S052

    [2]

    COVER

    KOB

    53.

    YN15V00017S053

    [2]

    SPRING

    KOB SPRING

    54.

    YN15V00017S054

    [2]

    SEAT

    KOB

    55.

    2436U1384S8

    [2]

    VALVE

    KOB

    56.

    2483U223S4

    [2]

    SPRING

    KOB

    57.

    2436U1139S10

    [2]

    PLUG

    KOB

    58.

    YN15V00017S058

    [2]

    O-RING

    KOB

    59.

    ZD12P00900

    [2]

    O-RING

    KOB ID 08.80 ± 0.17 x OD 12mm

    60.

    ZS23C12035

    [8]

    SCREW,Hex Socket Head, M12 x 35mm

    KOB M12x1.75x35mm

    . .

    YN15V00017R100

    [1]

    REPAIR KIT

    KOB CONSISTS OF ITEM,14X9

    . .

    YN15V00017R200

    [1]

    REPAIR KIT

    KOB CONSISTS OF ITEM,11X1,22X2

    . .

    YN15V00017R300

    [1]

    REPAIR KIT

    KOB CONSISTS OF ITEM,4X1,12X1
