R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump

    Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers

    Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers
    • Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers
    • Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers
    • Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers
    • Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers
    • Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers
    • Buy cheap R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump from wholesalers

    R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump

    Ask Lasest Price
    Brand Name : PNC
    Model Number : R140-7, R140-7, R140-9
    Price : USD 150-165/PC
    Payment Terms : T/T, Western Union, Paypal
    Delivery Time : 1-3 working days
    Supply Ability : 1000pcs/months
    • Product Details
    • Company Profile

    R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump

    R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump


    R140-9 EPPR Valve XJBN-00382 Solenoid Valve for K3V63DT Hydraulic Pump


    DescriptionR140-9 EPPR Valve, XJBN-00382 Prop Valve, K3V63DT EPPR Valve
    ApplicationR140-7 Excavator
    ModelR160-7, R180-7, R170W-7
    Part No.XJBN-00382
    QualityKorea quality, new
    Weight2.5-3.5 kgs
    PackingCarton box, color box
    MOQ1PC
    Lead timeAbout 1-3 working days
    PaymentTT, Western union, Paypal
    Warranty3 Months
    Shipping PortHuangpu Old Port, Shenzhen Yantian,Guangzhou

    R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump


    Compatible models:


    7 SERIES WHEEL EXCAVATOR R140W7 R140W7A R170W7 R170W7A

    7-SERIES CRAWLER EXCAVATOR R110-7 R110-7A R140LC-7 R140LC-7A R160LC7 R160LC7A R180LC7 R180LC7A


    9-SERIES CRAWLER EXCAVATOR R1200-9 R140LC9 R140LC9A R140LC9S R140LC9V R160LC9 R160LC9A R160LC9S R180LC9 R180LC9A R180LC9S

    9-SERIES WHEEL EXCAVATOR R140W9 R140W9A R140W9S R160W9A R170W9 R170W9S R180W9A R180W9S


    Parts on R140-7 Group Regulator:


    Pos.Part NoQtyParts nameComments
    *.@[1]MAIN PUMPSEE 4010
    *-1.XJBN-00453[1]REGULATOR(R) ASSY
    *-2.XJBN-00452[1]REGULATOR(F) ASSY
    079.XJBN-00382[1]EPPR VALVE ASSY
    405.XJBN-00449[4]SCREW
    412.XJBN-00448[2]SCREW
    413.XJBN-00447[2]SCREW
    436.XJBN-00446[2]SCREW
    438.XJBN-00445[6]SCREW
    438.XJBN-00445[10]SCREW
    466.XJBN-00356[1]PLUG
    496.XJBN-00032[6]PLUG
    496.XJBN-00032[5]PLUG
    601.XJBN-00317[1]CASING
    N611.XJBN-00444[1]LEVER-FEED BACK
    612.XJBN-00315[1]LEVER-1
    613.XJBN-00314[1]LEVER-2
    614.XJBN-00313[1]PLUG-CENTER
    615.XJBN-00312[1]PLUG-ADJUST
    621.XJBN-00311[1]PISTON-COMPENSATOR
    622.XJBN-00346[1]CASE-PISTON
    623.XJBN-00309[1]ROD-COMPENSATOR
    624.XJBN-00308[1]SEAT(C)-SPRING
    625.XJBN-00307[1]SPRING-OUTER
    626.XJBN-00306[1]SPRING-INNER
    627.XJBN-00305[1]STEM(C)-ADJUST
    K627.XJBN-01024[1]STEM(C)-ADJUST
    628.XJBN-00304[1]SCREW(C)-ADJUST
    K628.XJBN-01025[1]SCREW(C)-ADJUST
    629.XJBN-00303[1]COVER(C)
    630.XJBN-00302[1]NUT-LOCK
    631.XJBN-00301[1]SLEEVE
    641.XJBN-00300[1]COVER-PILOT
    642.XJBN-00299[1]SCREW(QMC)-ADJUST
    643.XJBN-00298[1]PISTON-PILOT
    644.XJBN-00297[1]SEAT(Q)-SPRING
    645.XJBN-00296[1]STEM(Q)-ADJUST
    646.XJBN-00295[1]SPRING-PILOT
    647.XJBN-00294[1]STOPPER
    648.XJBN-00293[1]PISTON(QMC)
    651.XJBN-00292[1]SLEEVE
    652.XJBN-00291[1]SPOOL
    653.XJBN-00290[1]SEAT-SPRING
    654.XJBN-00289[1]SPRING-RETURN
    655.XJBN-00288[1]SPRING-SET
    656.XJBN-00287[1]COVER-BLOCK
    699.XJBN-00442[1]CASING
    708.XJBN-00286[1]O-RING
    722.XJBN-00285[2]O-RING
    723.XJBN-00284[2]O-RING
    724.XJBN-00044[9]O-RING
    725.XJBN-00231[1]O-RING
    728.XJBN-00097[1]O-RING
    730.XJBN-00230[1]O-RING
    732.XJBN-00283[3]O-RING
    732.XJBN-00820[3]O-RING
    732.XJBN-00820[2]O-RING
    733.XJBN-00282[1]O-RING
    734.XJBN-00281[1]O-RING
    735.XJBN-00280[1]O-RING
    K736.XJBN-01026[1]O-RING
    753.XJBN-00441[1]O-RING
    755.XJBN-00362[3]O-RING
    755.XJBN-00362[2]O-RING
    K756.XJBN-00279[1]O-RING
    763.XJBN-00094[1]O-RING
    801.XJBN-00440[3]NUT
    801.XJBN-00440[2]NUT
    K802.XJBN-01027[1]NUT
    814.XJBN-00439[1]RING-SNAP
    836.XJBN-00276[1]RING-SNAP
    858.XJBN-00438[2]RING-SNAP
    874.XJBN-00344[1]PIN
    875.XJBN-00273[4]PIN
    887.XJBN-00272[1]PIN
    897.XJBN-00343[1]PIN
    898.XJBN-00270[1]PIN
    924.XJBN-00269[1]SCREW-SET
    N925.XJBN-00268[1]SCREW(QI)-ADJUST
    K.XJBN-01194[1]REGULATOR KIT
    N.@[AR]NOT INDIVIDUALLY SUPPLIED


    Payment &Packing &Shipping:


    A). TT transfer, Western Union, Paypal, Moneygram are acceptable.


    B). Light goods inner box is neutral white with an strong outer box.Heavy goods wooden case with standard packing.If you have legally registered patent,

    we can pack the goods in your branded boxes after getting your authorization letters.


    C). Delivery time: depends on items you buy, most electric parts can shiped within 1-3 working days.


    D). DHL /Fedex /UPS /TNT/ARMEX/SF Express ,etc. normal express shipping way for small cargo.Russia,Kazakhstan, Ukraine Russia Special Line,

    Bangladesh,Myanmar,Vietnam ect, competitive shipping way no need you do customs clearance.Door to Door.


    R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump

    R170W 9 R140W 9 EPPR Valve XJBN 00382 For K3V63DT Hydraulic Pump


    Warranty Statement:


    1. Warranty Type: We will replace the product which have quality problem.


    2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.

    Contact with us and offer the data, photos of the problem items


    3. You need to pay for the replacement charge for following condition:

    * Wrong Order from customer.
    * Natural Disasters cause the damage.
    * Error installation, improper use.
    * The machine and reducer work over time and over load.
    * Lost by any condition.
    * Human element destroyed.
    * Corrode with rust during stock and running.
    * Warranty Expired.


    FAQ :


    Q1: How can i make payment ?

    A : Bank transfer, Western union, Paypal, Paysend, or RMB.
    bank transfer take 2-3days, while we can arrange order once received the remittance copy.


    Q2: How fast you can do shipment?

    A: Stock items take 1-2days, no stock items 5-7 working days. It depends on the items and the quantity of your order. We will try best to ship goods on time,

    won't let you and your client down.


    Q3: If we dont find what we want on your website, what should we do?

    A: talk with us directly on whatsapp, email, wechat, or phone, we will check inquirys asap. excavator parts have thousands kinds, it's not possible to post

    all production online.


    Q5. Do your product been tested before delivery?

    A: Yes, all product been tested to make sure they are qualified to sell.


    Q4: Can we buy 1 pc of each item for quality testing?
    A: Yes, we value every customer, no matter order amount small or big, with grateful for your trust.
