420 00127 719753 Hydraulic Repair Parts DH220 5 K3V112DT EPPR Valve
719753 DH220-5 Prop Valve JCB JS220 EPPR Valve Hydraulic Pump
Repair Parts
| Description | JCB EPPR Valve, DH220-5 Prop Valve, K3V112DT Hydraulic Pump EPPR
Valve |
| Application | DH220-5 Excavator |
| Model | DH220-5, K3V112, JCB JS220 |
| Part No. | 420-00127, 719753 (solenoid MC609-7421120, SKC5-G24-106-1) |
| Quality | China made, Korea |
| Weight | 2.5-6.5kgs |
| Packing | Carton box, color box |
| MOQ | 1 pc |
| Lead time | About 1-3 working days |
| Payment | TT, Western union, Paypal, Paysend |
| Warranty | 3 Months |
| Shipping Port | Huangpu Old Port, Shenzhen Yantian,Guangzhou |
Doosan parts catalog:
SOLAR 200W-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 210W-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 210W-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 225LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 225LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 230LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 250LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 250LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 255LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 255LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
SOLAR 330LC-V
MAIN PUMP » VALVE;PROPORTIONAL 719753
Parts on DH220-5 Group Main Pump:
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| *. | 2401-9223KT | [1] | SEAL KIT;MAIN PUMP+REG. | |
| *. | 720777-PH | [1] | CYLINDER ASS'Y(R) | |
| *. | 720778-PH | [1] | CYLINDER ASS'Y(L) | |
| *. | 704543A | [2] | PISTON & SHOE ASS'Y | |
| *. | 717008 | [2] | SWASH PLATE ASS'Y | |
| *. | 717005 | [2] | TILTING PIN ASS'Y | |
| *. | 704550A | [2] | CHECK 1 ASS'Y | |
| *. | 704544A | [2] | CHECK 2 ASS'Y | |
| -. | 401-00356A | [1] | MAIN PUMP | |
| 111. | 124568 | [1] | SHAFT;DRIVING(F) | |
| 113. | 124569 | [1] | SHAFT;DRIVING(R) | |
| 114. | 113783 | [1] | COUPLING;SPLINE | |
| 123. | 219362 | [2] | BEARING;ROLLER | |
| 124. | 219363 | [2] | BEARING;SPACER | |
| 127. | 113784 | [4] | BEARING;SPACER | |
| 141. | 137491 | [1] | BLOCK;CYLINDER | |
| 141. | 137491 | [1] | BLOCK;CYLINDER | |
| 151. | *NA00796 | [18] | PISTON | |
| 152. | *NA01140 | [18] | PISTON | |
| 153. | 115786 | [2] | PLATE;PUSH | |
| 156. | 121437 | [2] | BUSH;SPHERICAL | |
| 157. | 113787 | [18] | SPRING;CYLINDER | |
| 158. | 113789 | [2] | SPACER | |
| 211. | 113790 | [2] | PLATE;SHOE | |
| 212. | 113780 | [1] | PLATE;SWASH | |
| 214. | 218550 | [1] | BUSH;TILTING | |
| 250. | 718424 | [1] | SUPPORT KIT | |
| 251. | 113791 | [2] | SUPPORT | |
| 261. | 113792 | [1] | COVER;SEAL(F) | |
| 271. | 113794 | [2] | CASING;PUMP | |
| 310. | 707849 | [1] | VALVE BLOCK KIT | |
| 312. | 113795 | [1] | BLOCK;VALVE | |
| 313. | 115798 | [1] | PLATE;VALVE(R) | |
| 314. | 115799 | [1] | PLATE;VALVE(L) | |
| 401. | 113797 | [8] | BOLT;SOCKET M20x210 | |
| 406. | 200846 | [4] | BOLT;SOCKET M8X20 | |
| 468. | 108847 | [3] | PLUG;VP | |
| 469. | 108848 | [2] | PLUG PF1/8 | |
| 490. | 224308 | [21] | PLUG | |
| 531. | 113807 | [1] | PIN;TILTING | |
| 532. | 113798 | [2] | PISTON;SERVO | |
| 534. | 113799 | [2] | STOPPER(L) | |
| 535. | 113800 | [2] | STOPPER(S) | |
| 541. | 113706 | [2] | SEAT | |
| 541. | 113706 | [2] | SEAT | |
| 543. | 113705 | [2] | STOPPER 1 | |
| 544. | 113703 | [2] | STOPPER 2 | |
| 545. | 200166 | [2] | BALL;STEEL | |
| 545. | 200166 | [2] | BALL;STEEL | |
| 548. | 113380 | [1] | PIN;FEEDBACK | |
| 702. | 220019 | [2] | O-RING 1BG35 | |
| 710. | 204452 | [2] | O-RING 1BG95 | |
| 717. | 201639 | [4] | O-RING 1BG145 | |
| 724. | 201765 | [16] | O-RING 1BP8 | |
| 725. | 201689 | [5] | O-RING 1BP11 | |
| 726. | S8000145 | [2] | O-RING 1BP14 | |
| 728. | 201721 | [3] | O-RING 1BP24 | |
| 732. | 220016 | [2] | O-RING 1BP18 | |
| 774. | 212231 | [1] | SEAL;OIL TCV40V | |
| 789. | 203480 | [2] | RING;BACK-UP T2P18 | |
| 79. | 719753 | [1] | VALVE;PROPORTIONAL | |
| 792. | 203418 | [2] | RING;BACK-UP T2G45 | |
| 806. | 201557 | [2] | NUT M16 | |
| 808. | 102048 | [2] | NUT M20 | |
| 824. | 202606 | [2] | RING;SNAP | |
| 885. | 113801 | [2] | PIN D8X12L | |
| 886. | 200678 | [2] | PIN;SPRING | |
| 901. | 212033 | [2] | BOLT;EYE | |
| 953. | 118892 | [2] | SCREW;SET M16X30L | |
| 954. | 113803 | [2] | SCREW;ADJUST | |
