213-0677 Oil Level Switch E320D CTA E345D Oil Pressure Sensor 2130677

Ask Lasest Price
Brand Name :	PNC
Model Number :	CAT E320D
Price :	USD 10-15/PC
Payment Terms :	T/T, Western Union, Paypal
Supply Ability :	1000pcs/months
Delivery Time :	1-2 working days

Add to Cart

Product Details
Company Profile

213-0677 Oil Level Switch E320D CTA E345D Oil Pressure Sensor 2130677

213-0677 Oil Level Switch E320D CTA E345D Oil Pressure Sensor 2130677

Description	E320D Oil Pressure Sensor, E345D Oil Level Switch, CAT Liquid Level Switch
Application	CAT Crawler Excavator
Model	CAT E320D, E325D, E330D, E336D, E349D
Part No.	213-0677, 2130677
Quality	China made
Weight	0.2-0.3kgs
Packing	Carton box
MOQ	1PC
Lead time	About 1-3 working days
Payment	TT, Western union, Paypal, Paysend, RMB
Warranty	3 Months
Shipping Port	Huangpu Old Port, Shenzhen Yantian,Guangzhou

Compatible equipment models: 2130677:
EXCAVATOR 311D LRR 312B L 312C 312C L 312D 312D L 312D2 312D2 GC 312D2 L 312E 312E L 313D 313D2 313D2 LGP

314D CR 314D LCR 314E CR 314E LCR 315B L 315C 315D L 316E L 317B LN 318B 318C 318D L 318D2 L 318E L 319C 319D

319D L 319D LN 320B 320C 320C FM 320C L 320D 320D FM 320D FM RR 320D GC 320D L 320D LN 320D LRR 320D RR

320D2 320D2 GC 320D2 L 320E 320E L 320E LN 320E LRR 320E RR 321B 321C 321D LCR 322C 322C FM 323D L 323D LN

323D SA 323D2 L 323E L 324D 324D FM 324D FM LL 324D L 324D LN 324E 324E L 324E LN 325C 325C FM 325D 325D FM

325D FM LL 325D L 325D MH 326D L 328D LCR 329D 329D L 329D LN 329E 329E L 329E LN 330C 330C FM 330C L 330C MH

330D 330D FM 330D L 330D LN 330D MH 336D 336D L 336D LN 336D2 336D2 L 336E 336E H 336E L 336E LH 336E LN 336F L

340D L 340D2 L 345B II 345B II MH 345B L 345C 345C L 345C MH 345D 345D L 345D L VG 349D 349D L 349E 349E L 349E

349F L 365B 365B II 365B L 365C 365C L 365C L MH 374D

FRONT SHOVEL 385C 5090B
GENERATOR SET C18 C32
INDUSTRIAL ENGINE 3126B C15 C18 C6.6 C7.1 C9 C9.3
MOBILE HYD POWER UNIT 323D L 323D LN 324D LN 325C 325D 325D L 329D L 329E 330C 330D 330D L 336D L 336E 336E HVG

345C L 349D L 349E 349E L HVG 365C L 385C 385C L
MOTOR GRADER 120M 2
SHOVEL LOGGER 345C
SITE PREP TRACTOR 2864C 586C
TRACK FELLER BUNCHER 1090 1190 1190T 1290T 1390

Parts for your 345D EXCAVATOR:

Pos.	Part No	Qty	Parts name
1.	3E-7427	[1]	ADAPTER
2.	130-5300	[1]	CLIP
3.	351-0283	[1]	VALVE AS-SHUTOFF (ENGINE OIL PAN)
	6V-7238	[1]	VALVE-SHUTOFF
3A.	238-5080	[1]	SEAL-O-RING
4.	9X-6451	[1]	PLUG-DRAIN (MAGNETIC)(ENGINE OIL PAN)
5.	336-7231	[1]	BELL AS-SUCTION
5A.	210-1743	[1]	ELBOW
6.	213-0677	[1]	SWITCH AS-LIQUID LEVEL (ENGINE OIL)
	102-8802	[1]	KIT-RECEPTACLE (2-PIN)
			(INCLUDES RECEPTACLE AS & WEDGE)
	9X-3401	[2]	PIN-CONNECTOR (16-GA TO 18-GA)
			-OR-
	126-1767	[2]	PIN-CONNECTOR (14-GA TO 16-GA)
7.	217-3673	[1]	SEAL-ISOLATION
8.	217-3674	[14]	FASTENER AS
9.	229-5331	[1]	PAN-OIL
10.	061-9458	[2]	SEAL-O-RING
11.	238-5082	[1]	SEAL-O-RING
12.	3E-8016 M	[2]	BOLT-SELF-LOCKING (M8X1.25X25-MM)
13.	389-3728	[2]	PLUG AS
			(EACH INCLUDES)
	360-3684	[1]	PLUG
13A.	238-5084	[1]	SEAL-O-RING
14.	5P-8211	[1]	SEAL-O-RING
15.	5P-8245	[2]	WASHER-HARD (13.5X25.5X3-MM THK)
16.	6A-5591 M	[2]	BOLT (M12X1.75X25-MM)
17.	6N-8863	[14]	WASHER (10.2X32X2.5-MM THK)
18.	6V-4249 M	[13]	BOLT (M10X1.5X50-MM)
19.	287-3049 M	[1]	STUD (M10X1.5X50-MM)
20.	9M-1974	[2]	WASHER-HARD (8.8X16X2-MM THK)

213-0677 Oil Level Switch E320D CTA E345D Oil Pressure Sensor 2130677
