    EC240B Swing Gearbox VOE14542163 Volvo Swing Reduction Gear VOE14566202

    Ask Lasest Price
    Brand Name : PNC
    Model Number : Volvo Excavator
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal
    Delivery Time : 2-3 working days
    • Product Details
    • Company Profile

    EC240B Swing Gearbox VOE14542163 Volvo Swing Reduction Gear VOE14566202

    EC240B Swing Gearbox VOE14542163 Volvo Swing Reduction Gear VOE14566202

    Description

    EC240 Swing Gearbox, EC240B Swing Reduction Gear, EC240C Swing Reducer

    Application

    Volvo Excavator

    Model

    EC240B, EC240C, EC250D

    Part No.

    VOE14542163, VOE14503783, SA7118-34100,VOE 14566202

    Quality

    OEM quality, China made

    Weight

    220-250kgs

    Packing

    Pack into wooden case

    MOQ

    1PC

    Lead time

    About 1-3 working days

    Payment

    TT, Western union, Paypal, Paysend, RMB

    Warranty

    3 Months

    Shipping Port

    Huangpu Old Port, Shenzhen Yantian,Guangzhou


    Models comprising the spare part VOE 14542163 Gearbox
    Excavators
    EC240B; EC240B;


    Aggregates comprising the spare part VOE 14542163 Gearbox
    EC240B Gearbox / Swing gearbox
    EC240B Hydraulic motor / Swing motor with mounting parts
    EC240B Gearbox / Swing gearbox
    EC240B Hydraulic motor / Swing motor with mounting parts

    EC240B Swing Gearbox VOE14542163 Volvo Swing Reduction Gear VOE14566202

    EC240B Swing Gearbox VOE14542163 Volvo Swing Reduction Gear VOE14566202


    Parts on group EC240B VOE14542163 swing reduction gear:

    Pos.Part NoQtyParts nameComments
    VOE14542163[1]Gearbox
    1.VOE14518703[1]Carrier
    2.SA1036-00530[1]Crankshaft
    3.SA1036-00550[3]Planetary Gear
    4.SA1036-00610[3]Pin
    5.SA7118-34231[3]Pin
    6.SA7118-34260[3]Bushing
    7.SA1036-00620[6]Washer
    8.SA9325-10012[3]Spring pin
    9.VOE14640028[1]Bearing
    10.SA1036-00710[1]Bearing
    11.SA1036-00630[1]Knob
    12.VOE14558605[1]Seal
    13.SA7118-01560[1]Plate
    14.SA7114-12590[4]Screw
    15.VOE14504206[1]Gear
    16.SA1036-00700[4]Pin
    17.SA7118-34340[1]Casing
    18.VOE14510986[1]Sun gear
    19.VOE984369[16]Hex. socket screw
    20.VOE14550896[1]Carrier
    21.SA7118-34410[1]Carrier
    22.SA7118-34420[3]Planetary Gear
    23.VOE14550897[3]Pin
    24.SA7118-34440[3]Needle bearing
    25.SA7118-34450[3]Washer
    26.SA7118-34460[3]Washer
    27.VOE13914468[3]Snap ring
    28.SA9325-08010[3]Spring pin
    29.SA7118-34470[1]Gear
    30.SA7118-34480[1]Washer
    31.SA7118-34490[1]Sun gear
    32.VOE984354[8]Hex. socket screw
    33.VOE14514384[1]PipeSER NO 10001-12701
    VOE14540597[1]PipeSER NO 12702-
    34.SA1012-01500[1]Valve
    35.[1]Casing
    36.SA9541-01085[1]Retaining ring
    37.VOE949329[1]Gasket
    100.VOE14526215[1]Overhaul kit
    200.VOE14627726[1]Housinginc 15,16,35


    Parts on group EC240B VOE14566202 swing reduction gear:

    Pos.Part NoQtyParts nameComments
    VOE14566202[1]Swing gearbox
    1.VOE14566206[1]Case
    2.VOE14552874[1]Ring
    3.VOE14566204[1]Collar
    4.VOE14566203[1]Shaft
    5.VOE14566205[1]Cover
    6.VOE14566209[1]Gear
    7.VOE947324[0016]Hex. socket screw
    8.VOE984088[12]Hex. socket screw
    9.VOE14552875[1]Roller bearing
    10.SA9415-43012[1]Plug
    11.VOE914167[1]Lubricating nipple
    12.VOE14566207[1]Seal
    13.VOE14566208[1]Roller bearing
    14.VOE914492[1]Snap ring
    15.SA7118-30380[1]Thrust ring
    16.VOE14566216[1]Gear
    17.VOE14880960[1]Retaining ring
    18.VOE14566222[1]Gear
    19.VOE14547278[1]Thrust washer
    20.VOE14540733[1]Pipe
    21.VOE14566210[1]Planet carrier
    22.VOE14566211[1]Planet carrier
    23.VOE14566215[4]Pin
    24.VOE14566212[4]Gear
    25.VOE14566213[4]Bushing
    26.VOE14556491[8]Washer
    27.SA9325-06012[4]Spring pin
    28.VOE14566217[1]Planet carrier
    29.VOE14566218[1]Planet carrier
    30.VOE14566219[3]Gear
    31.VOE14566220[3]Bearing
    32.VOE14566221[3]Pin
    33.SA9325-06012[3]Spring pin
    34.VOE14556491[6]Washer
    35.VOE950677[2]Pin
    36.VOE949329[1]Gasket
    37.VOE14722461[1]Draining valve


    Warranty Statement:

    1. Warranty Type: We will replace the product which have quality problem.


    2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.

    Contact with us and offer the data, photos of the problem items


    3. You need to pay for the replacement charge for following condition:

    * Wrong Order from customer.
    * Natural Disasters cause the damage.
    * Error installation, improper use.
    * The machine and reducer work over time and over load.
    * Lost by any condition.
    * Human element destroyed.
    * Corrode with rust during stock and running.
    * Warranty Expired.


    FAQ :

    Q1: How can i make payment ?

    A : Bank transfer, Western union, Paypal, Paysend, or RMB.
    bank transfer take 2-3days, while order will be arranged once received the remittance copy.


    Q2: How fast you can do shipment?

    A: Stock items take 1-2days, no stock items 5-7 working days. It depends on the items and the quantity of your order. We will try best to ship goods on time,

    won't let you and your client down.


    Q3: If we dont find what we want on your website, what should we do?

    A: talk with us directly on whatsapp, email, wechat, or phone, we will check inquirys asap. excavator parts have thousands kinds, it's not possible to post

    all production online.


    Q4. Do your product been tested before delivery?

    A: Yes, all product been tested to make sure they are qualified to sell.


    Q5: Can we buy 1 pc of each item for quality testing?
    A: Yes, we value every customer, no matter order amount small or big, with grateful for your trust.
