31N6-10010

[1]

MAIN PUMP ASSY

*-1,2,3,4

*.

31N6-10050

[1]

MAIN PUMP ASSY

*-1,2,3,4

*.

31N6-10051

[1]

MAIN PUMP ASSY

*-1,2,3,4

*-1.

@

[1]

MAIN PUMP UNIT

111.

XJBN-00077

[1]

DRIVE SHAFT(F)

113.

XJBN-00078

[1]

DRIVE SHAFT(R)

114.

XJBN-00351

[1]

COUPLING-SPLINE

123.

XJBN-00079

[2]

BEARING-ROLLER

123.

XJBN-00950

[2]

BEARING-ROLLER

124.

XJBN-00080

[2]

BEARING-NEEDLE

127.

XJBN-00081

[4]

SPACER-BEARING

NS141.

XJBN-00067

[2]

BLOCK-CYLINDER

NS151.

XJBN-00061

[18]

PISTON

NS152.

XJBN-00062

[18]

SHOE

*-11.

XJBN-01116

[1]

SET PLATE KIT

INCL153,156,158

153.

XJBN-00082

[2]

PLATE-SET

156.

XJBN-00353

[2]

BUSHING-SPHERICAL

156.

XJBN-00083

[2]

BUSHING-SPHERICAL

158.

XJBN-00354

[2]

SPACER

157.

XJBN-00084

[18]

SPRING-CYLINDER

211.

XJBN-00085

[2]

PLATE-SHOE

NS212.

XJBN-00070

[2]

PLATE-SWASH

S214.

XJBN-00071

[2]

BUSHING-TILTING

251.

XJBN-00086

[2]

SUPPORT

261.

XJBN-00087

[1]

COVER(F)-SEAL

271.

XJBN-00088

[2]

CASING-PUMP

312.

XJBN-00089

[1]

BLOCK-VALVE

S313.

XJBN-00065

[1]

PLATE-VALVE(R)

S314.

XJBN-00068

[1]

PLATE-VALVE(L)

401.

XJBN-00090

[8]

SCREW-HEX SOC HD

406.

XJBN-00355

[4]

SCREW-HEX SOC HD

466.

XJBN-00356

[2]

PLUG

468.

XJBN-00357

[4]

PLUG

490.

XJBN-00032

[18]

PLUG

NS531.

XJBN-00358

[2]

PIN-TILTING

532.

XJBN-00091

[2]

PISTON-SERVO

534.

XJBN-00092

[2]

STOPPER(L)

535.

XJBN-00093

[2]

STOPPER(S)

NS541.

XJBN-00073

[4]

SEAT

NS541.

XJBN-00859

[4]

SEAT

NS543.

XJBN-00074

[2]

STOPPER 1

NS543.

XJBN-00860

[2]

STOPPER

NS544.

XJBN-00076

[2]

STOPPER 2

NS544.

XJBN-00861

[2]

STOPPER

S545.

XJBN-00359

[4]

BALL-STEEL

NS548.

XJBN-00360

[2]

PIN-FEED BACK

K702.

XJBN-00918

[2]

O-RING

K710.

XJBN-00095

[1]

O-RING

K717.

XJBN-00096

[4]

O-RING

K724.

XJBN-00361

[16]

O-RING

K725.

XJBN-00362

[4]

O-RING

K728.

XJBN-00363

[4]

O-RING

K732.

XJBN-00912

[2]

O-RING

K774.

XJBN-00098

[1]

SEAL-OIL

789.

XJBN-00099

[2]

RING-BACK UP

792.

XJBN-00100

[2]

BACK-UP RING

806.

XJBN-00101

[2]

NUT

808.

XJBN-00364

[2]

NUT

824.

XJBN-00102

[2]

RING-SNAP

885.

XJBN-00103

[2]

PIN-VALVE PLATE

886.

XJBN-00365

[4]

PIN-SPRING

901.

XJBN-00104

[2]

BOLT-EYE

953.

XJBN-00105

[2]

SCREW-SET

954.

XJBN-00106

[2]

SCREW-SET

981.

XJBN-00156

[1]

NAME PLATE

981.

XJBN-00391

[1]

NAME PLATE

983.

XJBN-00341

[2]

PIN

*-2.

@

[1]

REGULATOR

SEE 4020

*-3.

@

[1]

GEAR PUMP

SEE 4030

*-4.

@

[1]

EPPR VALVE

SEE 4040

011.

XJBN-00060

[2]

PISTON SUB ASSY

SEE ILLUST

013.

XJBN-00063

[1]

CYLINDER ASSY(RH)

SEE ILLUST

014.

XJBN-00066

[1]

CYLINDER ASSY(LH)

SEE ILLUST

030.

XJBN-00069

[2]

SWASH PLATE SUB ASSY

SEE ILLUST

041.

XJBN-00072

[2]

CHECK VALVE ASSY 1

SEE ILLUST

042.

XJBN-00075

[2]

CHECK VALVE ASSY 2

SEE ILLUST

530.

XJBN-00366

[2]

TILTING PIN ASSY

SEE ILLUST

K.

XJBN-00971

[1]

PUMP UNIT SEAL KIT

SEE ILLUST
