Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor

    Buy cheap Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor from wholesalers

    Buy cheap Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor from wholesalers
    • Buy cheap Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor from wholesalers
    • Buy cheap Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor from wholesalers
    • Buy cheap Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor from wholesalers

    Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor

    Ask Lasest Price
    Brand Name : PNC
    Model Number : Hyundai R210LC-9, R210-7
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 1000pcs/months
    Delivery Time : 1-3 working days
    Price : USD 939-995/PC
    • Product Details
    • Company Profile

    Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor

    Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor​


    R210LC-9 Hyundai Travel Gearbox 31Q6-40020 Final Drive Withour Motor


    Description

    R210LC-9 Travel Reducer, R210-7 Final Drive withour motor, Hyundai Gearbox

    Application

    Hyundai R160LC-9S Excavator

    Model

    R210LC-9, R210-7, R160LC-9S, R180LC-9S

    Part No.

    31Q6-40020, 31Q6-40021, 31Q6-40022, 31N6-40040, 31N6-40041

    Quality

    China made, OEM quality

    Weight

    280-300 kgs

    Packing

    heavy items pack into wooden case

    MOQ

    1PC

    Lead time

    About 1-3 working days

    Payment

    TT, Western union, Paypal, Paysend, RMB

    Warranty

    3 Months

    Shipping Port

    Huangpu Old Port, Shenzhen Yantian,Guangzhou


    Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor

    Parts on group R210-9 TRAVEL REDUCTION GEAR (TYPE 1):


    Pos.

    Part No

    Qty

    Parts name

    Comments

    *.

    @

    [1]

    TRAVEL MOTOR ASSY

    SEE 4150

    *.

    @

    [1]

    TRAVEL MOTOR ASSY

    SEE 4150

    *-2.

    31Q6-40020

    [1]

    TRAVEL REDUCTION GEAR


    *-2.

    31Q6-40021

    [1]

    TRAVEL REDUCTION GEAR


    *-2.

    31Q6-40022

    [1]

    T/REDUCTION GEAR


    N1.

    XKAQ-00217

    [1]

    HOUSING


    2.

    XKAQ-00218

    [2]

    BEARING-MAIN


    2.

    XKAQ-00986

    [2]

    BEARING-MAIN


    3.

    XKAQ-00219

    [1]

    SEAL-FLOATING


    4.

    XKAQ-00220

    [1]

    SHIM


    5.

    XKAQ-00221

    [1]

    RETAINER


    6.

    XKAQ-00222

    [12]

    BOLT-HEX


    7.

    XKAQ-00223

    [2]

    PIN-PARALLEL


    8.

    XKAQ-00224

    [1]

    GEAR-RING


    9.

    XKAQ-00225

    [1]

    COUPLING


    9.

    39Q6-42170

    [1]

    COUPLING


    10.

    XKAQ-00226

    [1]

    CARRIER 2 ASSY


    10-1.

    XKAQ-00227

    [1]

    CARRIER 2


    10-2.

    XKAQ-00228

    [4]

    GEAR-PLANET 2


    10-3.

    XKAQ-00229

    [8]

    BEARING-NEEDLE 2


    10-4.

    XKAQ-00230

    [8]

    WASHER-THRUST


    10-5.

    XKAQ-00231

    [4]

    PIN 2


    10-6.

    XKAQ-00232

    [4]

    PIN-SPRING


    10-7.

    XKAQ-00208

    [2]

    RING-THRUST


    11.

    XKAQ-00653

    [1]

    CARRIER ASSY 1


    11-1.

    XKAQ-00234

    [1]

    CARRIER 1


    11-2.

    XKAQ-00235

    [1]

    GEAR-SUN 2


    11-3.

    XKAQ-00236

    [1]

    RING-RETAINING


    11-4.

    XKAQ-00237

    [3]

    GEAR-PLANET 1


    11-5.

    XKAQ-00238

    [3]

    BEARNG-NEEDLE 1


    11-6.

    XKAQ-00657

    [6]

    WASHER-THRUST


    11-7.

    XKAQ-00240

    [3]

    PIN 1


    11-8.

    XKAQ-00241

    [3]

    PIN-SPRING


    11-9.

    XKAQ-00655

    [1]

    PIN-SPRING


    12.

    XKAQ-00402

    [1]

    GEAR-SUN 1


    12.

    XKAQ-00795

    [1]

    GEAR-SUN 1


    13.

    XKAQ-00243

    [1]

    COVER


    14.

    XKAQ-00214

    [1]

    PAD


    15.

    XKAQ-00244

    [20]

    BOLT-SOCKET


    16.

    XKAQ-00245

    [2]

    SCREW-HEX SOCKET


    17.

    XKAQ-00246

    [3]

    PLUG-HYDRAULIC


    18.

    XKAQ-00247

    [3]

    O-RING


    19.

    XKAQ-00248

    [1]

    NAME PLATE


    19.

    XKAQ-00990

    [1]

    NAME PLATE


    N.

    @

    [AR]

    NOT SUPPLIED PARTS


    More Hyundai Travel Reduction Gear, Travel Gearbox we do:


    Part No.

    Name

    31E6-42000BG

    Travel reducer

    XKAH-00367

    Travel reducer

    31N6-40040, 31N6-40041, 31N6-40050

    Travel reducer

    39Q6-42100

    Travel reducer

    39Q6-42100

    Travel reducer

    XKAH-00901

    Travel reducer

    XKAH-01577, 39Q7-42100, 31Q7-40060

    Travel reducer

    31Q7-40060

    Travel reducer

    31N8-40070

    Travel reducer

    31N8-40071

    Travel reducer

    31N8-40072

    Travel reducer

    31Q9-40021

    Travel reducer

    31Q9-40022/23

    Travel reducer

    31Q9-40030

    Travel reducer

    31Q9-40023

    Travel reducer

    31N8-40070

    Travel reducer

    31N8-40071

    Travel gearbox

    31N9-40022

    Travel gearbox

    31Q9-40021

    Travel gearbox

    XKAH-01061

    Travel gearbox

    XKAY-01704

    Travel gearbox

    34E7-02500

    Travel gearbox


    Payment &Packing &Shipping:


    A). TT transfer, Western Union, Paypal, Moneygram are acceptable.


    B). Light goods inner box is neutral white with an strong outer box.Heavy goods wooden case with standard packing.If you have legally registered patent,

    we can pack the goods in your branded boxes after getting your authorization letters.


    C). Delivery time: depends on items you buy, most electric parts can shiped within 1-3 working days.


    D). DHL /Fedex /UPS /TNT/ARMEX/SF Express ,etc. normal express shipping way for small cargo.Russia,Kazakhstan, Ukraine Russia Special Line,

    Bangladesh,Myanmar,Vietnam ect, competitive shipping way no need you do customs clearance.Door to Door.


    Warranty Statement:


    1. Warranty Type: We will replace the product which have quality problem.


    2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.

    Contact with us and offer the data, photos of the problem items


    3. You need to pay for the replacement charge for following condition:

    * Wrong Order from customer.
    * Natural Disasters cause the damage.
    * Error installation, improper use.
    * The machine and reducer work over time and over load.
    * Lost by any condition.
    * Human element destroyed.
    * Corrode with rust during stock and running.
    * Warranty Expired.
