KRJ10290 Excavator Hydraulic Pump
CX210B Hydraulic Piston Pump K3V112DTP Hydraulic Pump For Excavator KRJ1029
| Description | CX210B Main Pump, K3V112DTP Hydraulic Pump |
| Application | CASE 210B Excavator |
| Model | E215, EH215 |
| Part No. | KRJ1029 |
| Quality | 100% new, China aftermarket or Korea |
| Weight | 145-165 kgs |
| Packing | Pack into standard export carton |
| MOQ | 1PC |
| Lead time | About 1-3 working days |
| Payment | TT, Western union, Paypal, Paysend, RMB |
| Warranty | 6 Months |
| Shipping Port | Huangpu Old Port, Shenzhen Yantian,Guangzhou |
Tips: To ensure client buy correct parts from China, parts details like model, part no. pump code, photo or size are required.
more details more good, all these infos are aim to supply you CORRECT parts to fit well with machine.
CASE CX210B CX240B K3V112DTP Hydraulic Pump Parts Catalog:
| Pos. | Part No | Qty | Parts name | Comments |
| 1. | KRJ10290 | [1] | HYDRAULIC PUMP | SUM See Figure 08-87 - 08-91 |
| 1. | KRJ10290R | [1] | REMAN-HYD PUMP | RAC CX210B CRAWLER EXCAVATOR TIER 3 (NA), STANDARD - COUPLING (1/07-) |
| 1. | KRJ10290C | [1] | CORE-HYDRAULIC PUMP | RAC Return Number |
| 2. | 166370A1 | [1] | FLANGE | SUM Flange |
| 3. | KHJ2656 | [2] | GROMMET | SUM |
| 4. | 862-20055 | [4] | HEX SOC SCREW,M20 x 55mm, Cl 12.9 | SUM Superseded by part number: 108R018Z055N |
| 5. | KRJ10340 | [1] | COUPLING | SUM Incl. 6 - 8 |
| 6. | KRJ10650 | [1] | COUPLING | SUM Superseded by part number: KRJ10340 |
| 7. | KRJ10660 | [4] | INSERT | SUM Coupling |
| 8. | KRJ10670 | [1] | INSERT | SUM Coupling |
| 9. | 166347A1 | [8-9] | BOLT,Sems, M10 x 30mm | SUM |
| 10. | KHJ18180 | [2] | STUD | SUM Incl. 11, Replaces KHJ11380 |
| 11. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
CX210B Hydraulic Pump Repair Parts:
| Pos. | Part No | Qty | Parts name | Comments |
| . . | KRJ10290 | [1] | HYDRAULIC PUMP | SUM Includes All Parts On Figures 08-87 - 08-91 |
| . . | KRJ10290R | [1] | REMAN-HYD PUMP | RAC CX210B CRAWLER EXCAVATOR TIER 3 (NA), PISTON (1/07-) |
| . . | KRJ10290C | [1] | CORE-HYDRAULIC PUMP | RAC Return Number |
| 1. | LJ014510 | [1] | HYDRAULIC PUMP | SUM See Figure 08-88 |
| 1. | LJ014510R | [1] | REMAN-HYD PUMP | RAC CX210B CRAWLER EXCAVATOR TIER 3 (NA), PISTON (1/07-) |
| 1. | LJ014510C | [1] | CORE-HYDRAULIC PUMP | RAC Return Number |
| . . | TJ00765 | [2] | PISTON | SUM Incl. 24, 25 |
| 24. | NSS | [9] | NOT SOLD SEPARAT | CON Piston |
| 25. | NSS | [9] | NOT SOLD SEPARAT | CON Shoe |
| . . | LJ014500 | [1] | BARREL | SUM Incl. 27, 28 |
| 27. | NSS | [1] | NOT SOLD SEPARAT | CON Block, Cylinder |
| 28. | NSS | [1] | NOT SOLD SEPARAT | CON Plate |
| . . | LJ014490 | [1] | BARREL | SUM Incl. 30, 31 |
| 30. | NSS | [1] | NOT SOLD SEPARAT | CON Block, Cylinder |
| 31. | NSS | [1] | NOT SOLD SEPARAT | CON Plate |
| . . | LR00552 | [2] | PLATE | SUM Incl. 33, 34 |
| 33. | NSS | [1] | NOT SOLD SEPARAT | CON Plate |
| 34. | NSS | [1] | NOT SOLD SEPARAT | CON Bushing |
| . . | TNP0022 | [1] | VALVE | SUM Check; Incl. 36 - 38 |
| 36. | NSS | [1] | NOT SOLD SEPARAT | CON Seat |
| 37. | NSS | [1] | NOT SOLD SEPARAT | CON Stopper |
| 38. | NSS | [1] | NOT SOLD SEPARAT | CON Ball |
| . . | TNP0023 | [2] | VALVE | SUM Check; Incl. 40 - 42 |
| 40. | NSS | [1] | NOT SOLD SEPARAT | CON Seat |
| 41. | NSS | [1] | NOT SOLD SEPARAT | CON Stopper |
| 42. | NSS | [1] | NOT SOLD SEPARAT | CON Ball |
| 43. | LJ014460 | [1] | VALVE SECTION | SUM See Figure 08-89 |
| . . | 160161A1 | [2] | LEVER ASSY. | SUM Incl. 63, 64 |
| 63. | NSS | [1] | NOT SOLD SEPARAT | CON Pin |
| 64. | NSS | [1] | NOT SOLD SEPARAT | CON Pin |
| 65. | 160033A1 | [1] | DRIVE SHAFT | SUM |
| 66. | 160034A1 | [1] | DRIVE SHAFT | SUM |
| 67. | LB00535 | [1] | COUPLING | SUM |
| 68. | TB00026 | [2] | BEARING, ROLLER, CYL,40mm ID x 90mm OD x 23mm W | SUM |
| 69. | TB00082 | [2] | NEEDLE BEARING,35 mm ID x 47 mm OD x 30 mm | SUM |
| 70. | 156963A1 | [4] | SPACER | SUM |
| 71. | TR00047 | [2] | PLATE | SUM |
| 72. | 169288A1 | [2] | BUSHING | SUM |
| 73. | 156960A1 | [18] | SPRING | SUM |
| 74. | 160113A1 | [2] | PLATE | SUM Shoe |
| 75. | TPP0080 | [2] | SUPPORT | SUM |
| 76. | 160334A1 | [1] | COVER | SUM |
| 77. | LJ014520 | [2] | HYDRAULIC PUMP | SUM |
| 78. | TJ00067 | [1] | VALVE BLOCK | SUM |
| 79. | NSS | [1] | NOT SOLD SEPARAT | CON Cover |
| 80. | 167078A1 | [8] | BOLT,M8 x 40mm, Cl 12.9 | SUM M8 x 40; 12,9 |
| 81. | 861-8020 | [4] | HEX SOC SCREW,M8 x 20mm, Cl 12.9 | CAS Superseded by part number: 86512138 |
| 82. | 863-10020 | [4] | HEX SOC SCREW,M10 x 20mm, Cl 12.9 | CAS |
| 83. | 155496A1 | [2] | PLUG | SUM |
| 84. | TLM0023 | [2] | PLUG | SUM |
| 85. | 155471A1 | [4] | PLUG | SUM |
| 86. | LK00003 | [27] | PLUG | SUM |
| 87. | TJ00066 | [2] | PISTON | SUM |
| 88. | TG00286 | [2] | STOP LOCK | SUM |
| 89. | 160116A1 | [2] | STOP | SUM |
| 90. | LE01176 | [2] | O-RING | SUM Superseded by part number: 154553A1 |
| 91. | LE013510 | [2] | O-RING | SUM (used under cover on top of pump or under aux gear pump) |
| 92. | LE013500 | [4] | O-RING | SUM |
| 93. | LE013470 | [16] | O-RING | SUM Superseded by part number: LE022170 |
| 94. | LE013410 | [6] | O-RING | SUM |
| 95. | LE013490 | [2] | O-RING | SUM |
| 96. | LE013440 | [4] | O-RING | SUM |
| 97. | LE01177 | [2] | O-RING | SUM Superseded by part number: 154489A1 |
| 98. | LE01178 | [1] | OIL SEAL | SUM Superseded by part number: LE018730 |
| 99. | 153970A1 | [2] | BACK-UP RING | SUM |
| 100. | 154017A1 | [2] | BACK-UP RING | SUM |
| 101. | 164R016VR | [2] | NUT | SUM |
| 102. | 829-1420 | [2] | NUT,M20, Cl 10 | CAS Superseded by part number: 9847024 |
| 103. | 800-1140 | [2] | SNAP RING,M40, Ext | CAS Superseded by part number: 370006 |
| 104. | 156954A1 | [2] | DOWEL | SUM |
| 105. | 338W060Z014B | [4] | LINCH PIN | SUM |
| 106. | 126R010SR | [2] | EYEBOLT | SUM BOLT, EYE |
| 107. | LA00036 | [2] | SET SCREW,Hex | SUM |
| 108. | 160296A1 | [2] | SET SCREW | SUM |
| 109. | NSS | [1] | NOT SOLD SEPARAT | CON Name Plate |
| 110. | LA00027 | [2] | RIVET | SUM |
Payment &Packing &Shipping:
A). TT transfer, Western Union, Paypal, Moneygram are acceptable.
B). Light goods inner box is neutral white with an strong outer box.Heavy goods wooden case with standard packing.If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
C). Delivery time: depends on items you buy, most electric parts can shiped within 1-3 working days.
Warranty Statement:
1. Warranty Type: We will replace the product which have quality problem.
2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.
Contact with us and offer the data, photos of the problem items
3. You need to pay for the replacement charge for following condition:
* Wrong Order from customer.
* Natural Disasters cause the damage.
* Error installation, improper use.
* The machine and reducer work over time and over load.
* Lost by any condition.
* Human element destroyed.
* Corrode with rust during stock and running.
* Warranty Expired.
